Image Interlace

Below are images demonstrating different interlacing modes applied via the build pipeline: PNG Line (Adam7), JPEG Plane (progressive), and baseline files with no interlacing.

Demonstration

These examples are best observed when images load gradually. Please see the How to Simulate Slow Loading section for instructions on simulating a slow network connection in your browser.

PNG (Adam7 Interlaced)

JPEG (Progressive, Plane)

Baseline (No Interlace)

How to Simulate Slow Loading

To clearly see the difference between PNG Adam7 interlacing, JPEG progressive encoding, and baseline images, you should load this page with a throttled network connection. Modern browsers allow you to simulate slow bandwidth in their developer tools:

Google Chrome / Edge

1. Press F12 to open DevTools
2. Go to the Network tab
3. Find the Throttling dropdown
4. Choose Slow 3G or add a custom profile (e.g. 500 kbps)

Firefox

1. Press F12
2. Open the Network panel
3. Click the No Throttling dropdown
4. Choose Regular 3G or Custom

Safari (Mac)

1. Enable the Develop menu in Safari preferences
2. Go to Develop → Network
3. Select a throttling option like 3G or Custom

With throttling enabled, reload this page. You'll see how PNG interlacing paints in a checkerboard-like fashion, JPEG progressive shows a blurry full image that sharpens in passes, and baseline images load top-to-bottom.

Configuration

Interlacing is controlled via option.image.interlace in config.json. Global rules apply to all PNG and JPEG files, while specific overrides are added for the image_interlace example folder:

"option": {
  "image": {
    "interlace": [
      { "mode": "Plane", "pattern": "**/*.{jpg,jpeg}" },
      { "mode": "Line", "pattern": "**/*.png" },
      { "pattern": "asset/image/content/example/image_interlace/**/*_line.png", "mode": "Line" },
      { "pattern": "asset/image/content/example/image_interlace/**/*_plane.{jpg,jpeg}", "mode": "Plane" },
      { "pattern": "asset/image/content/example/image_interlace/**/*.{png,jpg,jpeg}", "mode": "None" }
    ]
  }
}

Sources

Photo Gallery

The gallery on this page is powered by the PhotoSwipe JavaScript library. For more information, see the Photo Gallery example page.

Example Image Source

Image	Name	Source
	landscape-mountains-nature-lake.jpeg	Source: https://static.pexels.com Original Link ( no longer exists at this location ): https://static.pexels.com/photos/4062/landscape-mountains-nature-lake.jpeg
